OrCAD X Standard

SKU: POX100

alt text
alt text
alt text

OrCAD X Standard includes:

     OrCAD X Capture

alt text

     OrCAD CIS

alt text

     OrCAD PCB Designer

alt text

     Basic PSpice simulation

alt text

     Vendor neutral export IPC-2581

alt text

     3D Step file export to CAD

alt text

OrCAD ® PCB Designer Standard is a professional-grade solution for printed circuit board design, ideal for projects with moderate complexity across commercial and industrial applications. It includes OrCAD Capture for schematic entry, OrCAD PCB Editor, and the Component Information System (CIS), which comes standard for integrated part management. The platform features a high-performance Constraint Manager for managing electrical and physical design rules, ensuring design intent is maintained throughout the layout process. Fully compatible with Allegro tools, it also includes DFM and DFA capabilities to validate manufacturability and assembly readiness early in the design cycle—reducing rework, improving production efficiency, and supporting reliable product delivery
